Create your own OutlinedUrlTextField — AI was used to create this image

OutlinedUrlTextField in Jetpack Compose

If you’ve worked with Jetpack Compose, chances are you’ve used the common OutlinedTextField at some point in your app.

While it works well for general text input, handling URLs within this component can be less than ideal. That’s why I want to share our custom implementation: OutlinedUrlTextField, a tailored solution for managing URLs more effectively.

You can find a complete example of how to create and use this component here: GitHub Repository.

How is it implemented?

@Suppress("ReusedModifierInstance")
@Composable
fun OutlinedUrlTextField(
    value: String,
    onValueChange: (String) -> Unit,
    onUrlClick: (url: String) -> Unit,
    modifier: Modifier = Modifier,
    enabled: Boolean = true,
    readOnly: Boolean = false,
    textStyle: TextStyle = LocalTextStyle.current,
    label: @Composable (() -> Unit)? = null,
    placeholder: @Composable (() -> Unit)? = null,
    leadingIcon: @Composable (() -> Unit)? = null,
    trailingIcon: @Composable (() -> Unit)? = null,
    prefix: @Composable (() -> Unit)? = null,
    suffix: @Composable (() -> Unit)? = null,
    supportingText: @Composable (() -> Unit)? = null,
    isError: Boolean = false,
    keyboardOptions: KeyboardOptions = KeyboardOptions.Default,
    keyboardActions: KeyboardActions = KeyboardActions.Default,
    singleLine: Boolean = false,
    maxLines: Int = if (singleLine) 1 else Int.MAX_VALUE,
    minLines: Int = 1,
    interactionSource: MutableInteractionSource = remember { MutableInteractionSource() },
    shape: Shape = OutlinedTextFieldDefaults.shape,
    colors: TextFieldColors = OutlinedTextFieldDefaults.colors(),
) {
    val urlStyle = SpanStyle(
        color = MaterialTheme.colorScheme.primary,
        textDecoration = TextDecoration.Underline
    )
    val visualTransformation = UrlTransformation(urlStyle, onUrlClick)
    if (enabled && !readOnly) {
        androidx.compose.material3.OutlinedTextField(
            value = value,
            modifier = modifier,
            onValueChange = onValueChange,
            enabled = enabled,
            readOnly = readOnly,
            textStyle = textStyle,
            label = label,
            placeholder = placeholder,
            leadingIcon = leadingIcon,
            trailingIcon = trailingIcon,
            prefix = prefix,
            suffix = suffix,
            supportingText = supportingText,
            isError = isError,
            visualTransformation = visualTransformation,
            keyboardOptions = keyboardOptions,
            keyboardActions = keyboardActions,
            singleLine = singleLine,
            maxLines = maxLines,
            minLines = minLines,
            interactionSource = interactionSource,
            shape = shape,
            colors = colors,
        )
    } else {
        BasicTextField(
            value = value,
            onValueChange = onValueChange,
            modifier = modifier.padding(top = 8.dp),
            enabled = enabled,
            readOnly = readOnly,
            textStyle = textStyle,
            keyboardOptions = keyboardOptions,
            keyboardActions = keyboardActions,
            singleLine = singleLine,
            maxLines = maxLines,
            minLines = minLines,
            visualTransformation = visualTransformation,
            interactionSource = interactionSource,
            decorationBox = {
                OutlinedTextFieldDefaults.DecorationBox(
                    value = value,
                    innerTextField = {
                        Text(
                            text = value.buildAnnotatedStringWithUrlHighlighting(
                                style = urlStyle,
                                onUrlClick = onUrlClick,
                            ),
                        )
                    },
                    enabled = enabled,
                    singleLine = singleLine,
                    visualTransformation = visualTransformation,
                    interactionSource = interactionSource,
                    isError = isError,
                    label = label,
                    placeholder = placeholder,
                    leadingIcon = leadingIcon,
                    trailingIcon = trailingIcon,
                    prefix = prefix,
                    suffix = suffix,
                    supportingText = supportingText,
                    colors = colors,
                )
            },
        )
    }
}

The signature of OutlinedUrlTextField is very similar to the common OutlinedTextField, with one key difference: it includes a listener (onUrlClick: (url: String) -> Unit) that triggers when the user clicks on a URL.

To break down how it works, let’s divide the implementation into two modes:

📝 Editing Enabled

When editing is enabled, our component is essentially a OutlinedTextField from androidx.compose.material3. However, we need to customize its behaviour to highlight URLs dynamically.

To achieve this, we use a custom VisualTransformation (UrlTransformation), which detects URLs in the text and applies styling to make them visually distinct and clickable.

private class UrlTransformation(
    private val style: SpanStyle,
    private val onUrlClick: (url: String) -> Unit,
) : VisualTransformation {
    override fun filter(text: AnnotatedString): TransformedText = TransformedText(
        text = text.text.buildAnnotatedStringWithUrlHighlighting(style, onUrlClick),
        offsetMapping = OffsetMapping.Identity,
    )
}

UrlTransformation is a custom VisualTransformation in Jetpack Compose that detects and highlights URLs in a TextField using a given SpanStyle. It applies styling and makes URLs clickable, triggering onUrlClick when tapped. The transformation does not affect text input or cursor behaviour (OffsetMapping.Identity).

To detect URLs in the text, we use the function buildAnnotatedStringWithUrlHighlighting.

This function scans the input text, identifies URLs using a regex pattern (Patterns.WEB_URL), and applies a SpanStyle to highlight them. Additionally, it makes the URLs clickable by attaching a listener that triggers onUrlClick(url).

fun String.buildAnnotatedStringWithUrlHighlighting(
    style: SpanStyle,
    onUrlClick: (url: String) -> Unit = {},
): AnnotatedString = buildAnnotatedString {
    val text = this@buildAnnotatedStringWithUrlHighlighting
    append(text)
    text.split("\\s+".toRegex())
        .filter { Patterns.WEB_URL.matcher(it).matches() }
        .forEach { url ->
            val startIndex = text.indexOf(url)
            val endIndex = startIndex + url.length
            addStyle(
                style = style,
                start = startIndex,
                end = endIndex,
            )
            addLink(
                clickable = LinkAnnotation.Clickable(
                    tag = url,
                    styles = TextLinkStyles(style),
                    linkInteractionListener = { onUrlClick(url) },
                ),
                start = startIndex,
                end = endIndex,
            )
        }
}

This function detects URLs in a string and highlights them using SpanStyle, making them clickable in a Jetpack Compose TextField or Text.

How it Works

1. Extracts the original text and appends it to buildAnnotatedString.
2. Splits the text into words using whitespace as a separator.
3. Filters valid URLs using Patterns.WEB_URL.matcher(it).matches().
4. Finds the position of each URL (startIndex, endIndex).
5. Applies the provided SpanStyle to visually highlight the URL.
6. Adds a clickable link (addLink), triggering onUrlClick(url) when tapped.

🔏 Editing Not Enabled

When editing is disabled, we use a BasicTextField instead of OutlinedTextField. However, if we don’t customize it, the component will look plain and unstyled, lacking the visual consistency of an OutlinedTextField.

BasicTextField

How to Match the OutlinedTextField Style?

To make it visually similar to OutlinedTextField, we apply a custom DecorationBox, which replicates the outlined style, paddings, and background.

Additionally, we set innerTextField to support URL highlighting, ensuring that URLs remain visually distinct and clickable even in read-only mode.

Here’s how it looks:

decorationBox = {
    OutlinedTextFieldDefaults.DecorationBox(
        value = value,
        innerTextField = {
            Text(
                text = value.buildAnnotatedStringWithUrlHighlighting(
                    style = urlStyle,
                    onUrlClick = onUrlClick,
                ),
            )
        },
        enabled = enabled,
        singleLine = singleLine,
        visualTransformation = visualTransformation,
        interactionSource = interactionSource,
        isError = isError,
        label = label,
        placeholder = placeholder,
        leadingIcon = leadingIcon,
        trailingIcon = trailingIcon,
        prefix = prefix,
        suffix = suffix,
        supportingText = supportingText,
        colors = colors,
    )
},

OutlinedUrlTextField vs OutlinedTextField — Enabled=false

And don’t forget to add the paddingTop to the BasicTextField, modifier = modifier.padding(top = 8.dp), If you don’t include this padding, the label will be cut off when the text is present, affecting the visual alignment with a standard OutlinedTextField.

And here you can see the final result, OutlinedUrlTextField vs OutlinedTextField:

OutlinedUrlTextField(
    value = text,
    onValueChange = { text = it },
    onUrlClick = {
        Log.d("OutlinedUrlTextField", "Open URL $it")
        Toast.makeText(context, it, Toast.LENGTH_SHORT).show()
    },
    modifier = Modifier.fillMaxWidth(),
    enabled = editMode,
    label = { Text("Label") },
)

EditModeEnabled=true

EditModeEnabled=false

You can find all the code: GitHub Repository
