Create Retrofit CallAdapter for Coroutines to handle response as states

In the past, we used to use JakeWharton/retrofit2-kotlin-coroutines-adapter in order to use Retrofit with Coroutines.

But since Retrofit supports the suspend modifier on functions for Kotlin now, we don’t have to do this anymore.
See Retrofit version 2.6.0 (2019–06–05)

So now using Retrofit with Coroutines is as simple as this

@GET("users/{id}")
suspend fun user(@Path("id") id: Long): User

Enough talking about using Retrofit and Coroutines because there are tons of articles about this and let’s talk about error handling.

In this article I will show how can we create our own Retrofit CallAdapter to handle the API calls errors and success states.

By the end of the article you should be able to do the following:

Sample

Create Network Response Sealed Class

First, let’s model our responses states by creating a sealed class that represents the API call response states.

Most probably we need 4 states:

1. Success which is a data class that should contain the body of the success state of the request.
2. ApiError which represents the non-2xx responses, it also contains the error body and the response status code.
3. NetworkError which represents network failure such as no internet connection cases.
4. UnknownError which represents unexpected exceptions occurred creating the request or processing the response, for example parsing issues.

Create our own Call transformer

In order to make Retrofit return NetworkResponse when topic() API call is triggered, we need to write a custom CallAdapter

First step to create our own CallAdapter is implementing Call interface from Retrofit

The method that has most of the logic in our implementation of the Call interface is enqueue.

What is the enqueue method?

Asynchronously send the request and notify callback of its response or if an error occurred talking to the server, creating the request, or processing the response.

So we will implement enqueue method and check the response, then return the correct callback.

enqueue takes a callback which has two methods to implement:

1. onResponse: which is invoked for a received HTTP response, this response could be success response or failure one.
   So we have to check here if the response is successful, we return the success state of our NetworkResponse sealed class
   If it’s not a success response, we try to parse the error body as the expected error data class we provide as a type, if the parse succeeded we return the error as ApiError state, otherwise it’s UnknownError.
2. onFailure: which is invoked when a network exception occurred talking to the server or when an unexpected exception occurred creating the request or processing the response.
   Here we can simply check if the exception is IOException then we return the NetworkError state, otherwise it should be UnknownError state.

enqueue method

The rest of the methods of Call interface are simple, we will just delegate them to the original call.

So the our Call implementation should look like this

NetworkResponseCall

Create your own CallAdapter

Now it’s time to create our CallAdapter

Creating CallAdapter is very straight forward, we will need to implement only two methods

responseType Returns the value type that this adapter uses when converting the HTTP response body to a Java object

adapt Returns an instance of T which delegates to call, here we will use our NetworkResponseCall that we just created.

Create your own CallAdapter Factory

Next step is creating our CallAdapter.Factory

CallAdapter.Factory has only one abstract method that we should implement which is get.

get method in the CallAdapter.Factory should return a callback adapter for interface methods that it could handle or null if it’s can’t be handled by this factory.

So simply our get method in our custom CallAdapter.Factory should check if the returnType is our sealed class for the API response calls, and then handle it.
If the caller isn’t asking for our Sealed Class, return null, this isn’t the right adapter.

What does this mean?

But there is something we need to know first about how suspend functions work with Retrofit.

@GET("users/{id}")
suspend fun user(@Path("id") id: Long): User

Behind the scenes this behaves as if defined as fun user(...): Call<User> and then invoked with Call.enqueue

So this means when we have a suspend function like this

suspend fun user(): ApiResponse<User, Error>

It’s actually

fun user(): Call<ApiResponse<User, Error>>

So after removing the Call type we have to make sure that the inner type is ApiResponse

Now we reached a point, where we have the response as ApiResponse<Success, Error>

Next, we need extract the success and error types from the ApiResponse parameterized type.

The base CallAdapter.Factory in Retrofit has a function named getParameterUpperBound which should help us getting the success/error types from the parameterized type ApiResponse

Then get the error converter and return

NetworkResponseAdapterFactory

Make retrofit aware of your Call Adapter

Finally you need to add our custom CallAdapterFactory to Retrofit while initializing it

Protip:

If you happen to have a generic error model that your API uses for most/all of the endpoints you can save yourself sometimes and code by creating a typealias that wraps this generic error model and the success type like this

typealias GenericResponse<S> = NetworkResponse<S, GenericApiError>

Sample Project:

I created a sample App, you can check it out on GitHub

Inspiration:

1. Square/retrofit/ErrorHandlingAdapter
2. Supercharging Retrofit with Kotlin

Feedback is always welcome :)
