Compose Navigation The Old Way

A guide on how to define string routes safely

Traditionally, navigation in Compose relies on defining routes as strings, which opens up a lot of flexibility but also introduces potential risks if not handled carefully. In this guide, we’ll walk through how to safely define string routes, break down the structure of these routes, and address common problems encountered when using this method.

What this article is not — a guide on the new type safe navigation

Click here to view the complete Destinationsource code

Understanding the Structure of Navigation Routes URI

Compose navigation routes use a string pattern to define the paths between composables. These strings can contain both required and optional arguments, which dictate how data is passed to different screens in the app. Let’s break down the key components that make up a string route:

1. Route Name: The base of the string that represents the destination. It could be a simple string like "home", "profile", or "details". This is the identifier of the composable you want to navigate to.

   Example:

val route = "profile"

2. Required Arguments: These are values that must be provided when navigating to a specific route. A required argument follows the pattern /{argumentID}, where / acts as the delimiter separating multiple required arguments, and {} enclose the argument ID.

Example:

val route = "profile/{userId}"

Here, userID is a required argument. When navigating to the profile screen, you need to provide a value for userID.

3. Optional Arguments: These arguments are not mandatory for the route to function and are defined using query parameter syntax. An optional argument follows the pattern argumentID={argumentID}. The ? prefix marks the start of optional arguments, and & is used as the delimiter to separate multiple optional arguments. Braces {} enclose the argument ID, which will be replaced with the actual argument when it is passed — the entire {argumentID} will be substituted by the provided argument (this same rule applies to required arguments as well).

Example:

val route = "search?query={query}"

The query parameter is optional. If it’s not provided, the screen can still be displayed, but without the query term.

Together, a complete route might look something like this:

val route = "profile/{userId}?showDetails={showDetails}&page={page}"

In this case, the userID is required, while showDetails and page are optional.

Case Study

Let’s take a case study of two screens:

1. A Form screen with three fields: Email, Phone number, social link
2. A profile screen that displays these information.

Let’s make the phone number and social link optional, the route for PROFILE_SCREEN accepts an email as a required argument, a phone number and social link as optional arguments. We follow the convention of using call backs to pass navController to screens using the signature
onNavigate: (route: String) -> Unit

The responsibility of generating the route is scoped to the screen that calls onNavigate

Since routes are defined as strings, navigating between screens requires that you embed the actual argument values within a route when needed, allowing for potential typos during route construction. This introduces a risk of your app crashing due to:

1. String Typing Errors: If you accidentally type profle/{userId} instead of profile/{userId}, it will break the navigation, as the navController object will have no record of that route. Such errors may not be immediately obvious.

2. Missing Arguments: If a required argument is omitted, the app will crash. For example, when navigating to profile/{userId}, if you do not provide the userID, navigation will fail.

3. Complexity with Multiple Arguments: When dealing with routes that require multiple arguments — especially if some are optional — it can become challenging to track what needs to be passed. The more complex the route becomes, the harder it is to ensure that the string is constructed correctly.

Handling routes in this manner within a production app that features many screens, each with its own set of arguments, can lead to a considerable amount of time spent debugging these routes. Clearly, there is a problem that requires an efficient solution.

How can this problem be better managed?

We need to define a route management model to mitigate errors. This model should reliably create routes with the correct patterns.

Aim: The model should guarantee correctness, have a straight forward signature, and offer friendly usage.

The solution Ipresent is a data type that uses Joshua Bloch’s builder pattern, leveraging Kotlin’s DSL to provide a very descriptive usage

The Destination Class API

The data type we will call Destination holds the following properties and function

Member Function

navRoute(block: Utility.() -> Unit = {})
Return value: A string representing the full route, including the actual arguments if provided (required or optional).
Parameters:
block: Utility.() -> Unit — a lambda block with access to utility functions used to modify the route during construction.

Companion Object Functions

generateRoute(routeID:String, block: Builder.() -> Unit = {}: Destination
Return value: A Destination instance representing the specified route.
Parameters:
routeID:String— the unique ID of the route.
block: Builder.() -> Unit — an optional lambda block with access to utility functions used to customise the route during construction.

Utility Class API

The utility class is an inner class the holds utitlity function used to append actual arguments to routes

Utility API Doc

Builder Class API

A nested builder class with utility functions to correctly create the route safely. The builder class is defined with the following functions

Builder API Doc

Sample Usage for Defining Routes and Navigating

Using the APIs to define a navigation route then becomes a simple task.

• To create a destination instance that holds navigation information we call generate() passing a route id which is the base string identifier
• To instantiate a destination with a required argument, generateRoute() accepts a lambda scoped to a receiver of type Builder. This lambda has access to withRequiredArgs() which is used to append required argument to the route under construction.
• To instantiate a destination with optional arguments, we append them to the route under construction using withOptionalArgs().

Caution: withOptionalArgs()accepts a varargof NamedNavArgument objects and not String. Since compose navigation component requires that optional arguments provides an explicit list of NamedNavArgument.

Here is an example!

Once the destinations are defined, the navigation action looks like this:

navController.navigate(FORM_ROUTE.navRoute())

This navigates the user to the FORM_ROUTE, which has no arguments.

This navigates the user to the PROFILE_ROUTE. Notice how we append argument values.

• An email is a required value, so it is appended via requiredArgs("sample@outlook.com").
• phone_number and url are optional values, so we append them in one call using optionalArgs("01478219", "http://www.mysociallink.com/profile")

The optional arguments — phone_number and url can be omitted, and if not provided, the default values 0102030455 and null will be used respectively.

Enforcing Type Safety For Argument

Let’s add another layer of safety, where we define an extension function on NavControllerinstance whose purpose is to enforce type safety for arguments.

Notice that optional argument have nullable types. The extension functions we define now serve as the entry point for our nav action. We do not need to directly navigate using PROIFILE_ROUTE, or FORM_ROUTE any longer.

Finally, adapting this solution for use in our sample case study
NavHost now looks like this

FormScreen() responsible for navigating to profile now looks like this

You can find the Destination source code here

Effectively managing navigation routes in Jetpack Compose can sometimes be an overwhelming task, especially for collaborative projects. Clearly, a structured approach is needed, and this guide offers one such method that leverages the Destination class and its builder to manage navigation routes. This approach ensures that routes are constructed consistently, helping to avoid runtime errors associated with string-based routes due to mismatched argument names or incorrect formatting. The insights shared in this guide provide a solid foundation for defining and navigating routes with clarity and confidence. By implementing these strategies, you’ll enhance the overall quality of your application’s navigation architecture, leading to a smoother user experience and more maintainable code.
